10mm or 20mm Latch Lock 4485
A range of 10mm and 20mm latch locks available in bright chrome. Secured with a padlock, these locks are ideal for applications such as Lockers.
Lock Options
| Product Code | Body Length | Head Width | Head Depth | E Dimension | Finish | Shackle Diameter | X Dimension | Inquire |
|---|---|---|---|---|---|---|---|---|
| 4464 | 10 | 29 | 16.5 | 3.5 | Bright Chrome | Min 5 – Max 6.5 | see Cams | Contact Sales |
| 4466 | 10 | 29 | 16.5 | 2 | Bright Chrome | Min 5 – Max 6.5 | see Cams | Contact Sales |
| 4477 | 10 | 29 | 16.5 | 2 | Bright Chrome | Min 6 – Max 8 | see Cams | Contact Sales |
| 4482 | 10 | 29 | 16.5 | 2 | Bright Chrome | Min 6 – Max 8 | see Cams | Contact Sales |
| 4484 | 10 | 29 | 16.5 | 2 | Bright Chrome | Min 6 – Max 8 | see Cams | Contact Sales |
| 4485 | 20 | 29 | 16.5 | 2 | Bright Chrome | Min 6 – Max 8 | see Cams | Contact Sales |
| 4486 | 10 | 29 | 16.5 | 2 | Bright Chrome | Min 6 – Max 8 | see Cams | Contact Sales |
| 4487 | 20 | 29 | 16.5 | 2 | Bright Chrome | Min 6 – Max 8 | see Cams | Contact Sales |
Standard Features
- Standard movements: 1, 2
- Lock Combinations: Padlock
- Standard finish: Bright chrome
- Panel thickness: 4 – 13.5mm (contact Sales Department)
- Mounting hole shape: Double D
- Recommended shackle diameter: Min 5mm – Max 8mm
- Dimension ‘E’ and ‘X’ specification: See Lock Options
- Dimension ‘B’ specification: See Cams
Additional Information
10mm or 20mm Latch Lock 4485 technical drawing
