26mm Sliding Door Lock 5860

A 26mm Sliding Door Lock 5860 in Bright or Black Chrome.

Featured Technicals
26mm Sliding Door Lock 5860 Technical Drawing
Lock Description

This lock is ideal for use on furniture with sliding door features such as cabinets and cupboards.

Have a question?
Lock Options
Product Code Key Series Combinations Body Length Head Height Head Width Head Depth Head Shape Housing Fixing Lock Type Movement X Dimension Enquire
5860 200 26 22 22 26 Cylindrical Screw Fix Key to lock 0 12.5
5861 200 26 22 22 26 Cylindrical Screw Fix Push to lock 0 10
Standard Features
  • Standard movements: 0 (see technical drawing)
  • Lock Combinations: 200 (1,000 on request)
  • Standard finish: Bright chrome, black chrome
  • M Keyed system supplied to order only
  • Lock bolt length = ‘X’: 5860 – 12.5mm; 5861 – 10mm

Additional information

26mm Sliding Door Lock 5860 technical drawing
