19mm-25mm Rim Lock 5864

A range of 19mm or 25mm Rim Locks available in a number of finishes.

Featured Technicals
19mm-25mm Rim Lock 5864 Technical Drawing
Lock Description

This lock has a fixed barrel and is ideal for use on items such as cupboards and cabinets.

Have a question?
Lock Options
Product Code Key Series Combinations Body Length Head Width Head Depth Head Shape Housing Fixing Lock Fixing Movement X Dimension Enquire
5864 200 25 16.3 25 Cylindrical Screw Fix Vertical 3 25
5865 200 19 16.3 19 Cylindrical Screw Fix Vertical 3 19
5866 200 25 16.3 25 Cylindrical Screw Fix Right Hand 3 25
5867 200 19 16.3 19 Cylindrical Screw Fix Right Hand 3 19
5868 200 25 16.3 25 Cylindrical Screw Fix Left Hand 4 25
5869 200 19 16.3 19 Cylindrical Screw Fix Left Hand 4 19
Standard Features
  • Standard movements: 3, 4
  • Lock Combinations: 200 (1,000 on request)
  • Standard finish: Bright chrome, bright nickel, black chrome
  • Fixing hole shape: Round
  • M Keyed system supplied to order only
  • Rosette 7008003: Available on request

Additional information

19mm-25mm Rim Lock 5864 technical drawing
